Condensing unit MC-H8-ZF13KE-TFD

Producer:
Copeland
Line: Scroll
Product code: MC-H8-ZF13KE-TFD
  • Cooling capacity [kW]:
    6.17
  • Displacement [m³/h]:
    11.7
  • Refrigerant:
    R22, R404A, R407A, R407F, R448A, R449A
  • Capacity control:
    None
  • Power supply:
    400V/3Ph/50Hz
Zapytaj

Data

Compressor technical data

Compressor model
ZF13K4E-TFD
Displacement
[m³/h]
11.7
Oil charge
[l]
1.90
Oil type
POE RL32-3MAF
Allowed oil types
POE RL32-3MAF, POE MOBIL EAL Arctic 22 CC
Capacity control
None

Compressor electrical data and limits

Compressor power supply
400V/3Ph/50Hz
Maximum continuous current
[A]
8.0
Locked rotor amperage
[A]
51.5

Condenser data

Condenser model
H8
Fan model
271
Fan quantity
1
Fans power
[W]
235
Fan current
[A]
2.55
Air flow
[m³/h]
3,600
Acoustic pressure (10m)
[dB(A)]
50.0

Condensing unit data

Receiver volume
[l]
7.9
Net weight
[kg]
77
Gross weight
[kg]
92
Housing
Optional
Approved refrigerants
R22, R404A, R407A, R407F, R448A, R449A

Dimensions

Length
[mm]
680
Height
[mm]
533
Width
[mm]
735

Connections

Suction connection thread diameter
[inch]
7/8
Liquid line diameter
[inch]
1/2

Performance

Invalid data supplied. Correct them and try again.
Performance
Evaporation
Ambiance

Cooling capacity [kW]

Evaporation temperature [°C]
Ambient temperature [°C]

-40
-35
-30
-25
-20
-15
-10
-5
0
5
7
20
2.25
2.90
3.63
4.45
5.38
6.40
7.51
8.73
10.03
11.42
12.01
27
2.02
2.60
3.25
3.99
4.82
5.74
6.75
7.85
9.04
10.32
10.86
32
1.86
2.38
2.97
3.64
4.40
5.24
6.17
7.19
8.30
9.50
10.01
35
1.76
2.24
2.79
3.42
4.13
4.93
5.81
6.78
7.84
8.99
9.48
38
1.67
2.11
2.62
3.20
3.86
4.61
5.44
6.36
7.37
8.47
41
1.57
1.97
2.43
2.97
3.59
4.28
5.06
5.93
6.88
43
1.51
1.87
2.31
2.81
3.40
4.06
4.80
5.63
46
1.41
1.73
2.12
2.58
3.11
3.71

Power consumption [kW]

Evaporation temperature [°C]
Ambient temperatura [°C]

-40
-35
-30
-25
-20
-15
-10
-5
0
5
7
20
2.00
2.10
2.22
2.36
2.53
2.73
2.95
3.20
3.48
3.78
3.92
27
2.25
2.35
2.48
2.63
2.80
3.00
3.23
3.49
3.77
4.08
4.22
32
2.45
2.56
2.70
2.85
3.03
3.23
3.46
3.72
4.01
4.32
4.46
35
2.59
2.71
2.84
3.00
3.18
3.38
3.61
3.87
4.16
4.48
4.62
38
2.74
2.86
3.00
3.16
3.34
3.54
3.78
4.04
4.33
4.65
41
2.91
3.03
3.17
3.33
3.51
3.72
3.95
4.21
4.50
43
3.02
3.15
3.29
3.45
3.63
3.84
4.07
4.33
46
3.21
3.33
3.48
3.64
3.82
4.03

Application range

Legend

  • Suction gas temperature: 25°C, liquid injection

Dimensions

Downloads

Safety manual, [1.4 MB]
Copeland
11-2014
Declaration, [140.9 KB]
Copeland
04-2019
EN
Catalogue, [8.2 MB]
Copeland
01-2022
PL
User manual, [1.5 MB]
Copeland
11-2012
EN
Folder, [1.5 MB]
Copeland
03-2016
EN
User manual, [401.2 KB]
Copeland
EN
Technical documentation, [339.2 KB]
Copeland
EN
Catalogue, [7.8 MB]
Copeland
01-2023
EN
Safety manual, , Copeland, 11-2014, [1.4 MB]
Declaration, EN, Copeland, 04-2019, [140.9 KB]
Catalogue, PL, Copeland, 01-2022, [8.2 MB]
User manual, EN, Copeland, 11-2012, [1.5 MB]
Folder, EN, Copeland, 03-2016, [1.5 MB]
User manual, EN, Copeland, [401.2 KB]
Technical documentation, EN, Copeland, [339.2 KB]
Catalogue, EN, Copeland, 01-2023, [7.8 MB]
