Reciprocating compressor 6MM-30X

Producer:
Copeland
Line: Stream
Product code: 6MM-30X
  • Cooling capacity [kW]:
    59.04
  • Displacement [m³/h]:
    121
  • Refrigerant:
    R134a, R404A, R407A, R407F, R448A, R449A, R450A, R454A, R454C, R455A, R513A
  • Capacity control:
    None, Step (option), Inverter (option)
  • Power supply:
    400V/3Ph/50Hz
Zapytaj

Data

Technical data

Displacement
[m³/h]
121
Cylinders quantity
6
Cylinder bore
[mm]
71.5
Cylinder stroke
[mm]
57.5
Oil charge
[l]
3.30
Oil type
POE RL32-3MAF
Type of lubrication
Oil pump
Net weight
[kg]
215

Electrical data and limits

Power supply
400V/3Ph/50Hz
Maximum continuous current
[A]
59.7
Locked rotor amperage
[A]
255.0
Maximum suction pressure
[bar]
22.5
Maximum discharge pressure
[bar]
32.5

Dimensions

Suction valve diameter
[inch]
2 1/8
Discharge valve diameter
[inch]
1 3/8
Length
[mm]
695
Height
[mm]
450
Width
[mm]
547

Other

Approved refrigerants
R134a, R404A, R407A, R407F, R448A, R449A, R450A, R454A, R454C, R455A, R513A
Allowed oil types
POE RL32-3MAF, POE MOBIL EAL Arctic 22 CC
Capacity control
None, Step (option), Inverter (option)
Protection rating
IP54 (IEC34)

Performance

Invalid data supplied. Correct them and try again.
Performance
Evaporation
Condensation

Cooling capacity [kW]

Evaporation temperature [°C]
Condensation temperature [°C]

-50
-45
-40
-35
-30
-25
-20
-15
-10
-5
5
13.67
18.80
25.41
33.73
43.98
56.41
71.26
10
12.64
17.59
23.87
31.72
41.39
53.11
67.14
83.72
103.11
15
11.54
16.31
22.27
29.66
38.74
49.76
62.96
78.61
96.97
118.27
20
10.37
14.96
20.60
27.54
36.04
46.35
58.74
73.46
90.78
110.95
25
9.13
13.54
18.86
25.35
33.27
42.89
54.46
68.25
84.54
103.57
30
7.83
12.06
17.07
23.11
30.45
39.37
50.12
62.99
78.25
96.15
35
6.48
10.52
15.20
20.80
27.57
35.79
45.73
57.68
71.90
88.68
40
8.92
13.29
18.43
24.63
32.16
41.29
52.31
65.50
81.15
45
7.29
11.32
16.02
21.64
28.48
36.79
46.89
59.04
73.56
50
9.32
13.56
18.61
24.75
32.25
41.41
52.53
65.92
55
7.31
11.07
15.54
20.98
27.66
35.89
45.96
58.21
60
8.59
12.46
17.18
23.03
30.31
39.33
62
7.60
11.22
15.65
21.17
28.06
36.65

Power consumption [kW]

Evaporation temperature [°C]
Condensation temperature [°C]

-50
-45
-40
-35
-30
-25
-20
-15
-10
-5
5
7.93
9.19
10.35
11.39
12.28
12.97
13.46
10
8.24
9.62
10.91
12.10
13.15
14.02
14.69
15.12
15.29
15
8.53
10.04
11.49
12.84
14.06
15.12
16.00
16.65
17.04
17.15
20
8.77
10.44
12.05
13.58
14.99
16.26
17.35
18.23
18.87
19.23
25
8.94
10.77
12.56
14.28
15.90
17.39
18.71
19.83
20.73
21.37
30
9.00
11.01
13.00
14.92
16.76
18.48
20.05
21.44
22.61
23.54
35
8.93
11.13
13.32
15.47
17.55
19.51
21.34
23.01
24.47
25.70
40
11.09
13.51
15.89
18.22
20.45
22.56
24.51
26.27
27.82
45
10.87
13.52
16.16
18.75
21.26
23.66
25.91
27.99
29.87
50
13.34
16.24
19.11
21.91
24.61
27.19
29.60
31.83
55
12.92
16.10
19.26
22.37
25.40
28.31
31.07
33.65
60
15.71
19.18
22.61
25.97
29.23
32.36
62
15.48
19.08
22.64
26.14
29.54
32.82

Application range

Legend

  • Suction gas superheating: 20 K
  • Suction gas temperature: 0°C
  • Suction gas temperature: 20°C, ASERCOM certified
  • Current operating conditions

Dimensions
