Reciprocating compressor 4MA-22X

Producer:
Copeland
Line: Stream
Product code: 4MA-22X
  • Cooling capacity [kW]:
    30.13
  • Displacement [m³/h]:
    61.7
  • Refrigerant:
    R22, R134a, R404A, R407A, R407C, R407F, R448A, R449A, R450A, R454A, R454C, R455A, R513A
  • Capacity control:
    None, Step (option), Inverter (option)
  • Power supply:
    400V/3Ph/50Hz
Ask

Data

Technical data

Displacement
[m³/h]
61.7
Cylinders quantity
4
Cylinder bore
[mm]
63.5
Cylinder stroke
[mm]
56.0
Oil charge
[l]
3.30
Oil type
POE RL32-3MAF
Type of lubrication
Oil pump
Net weight
[kg]
177

Electrical data and limits

Power supply
400V/3Ph/50Hz
Maximum continuous current
[A]
36.3
Locked rotor amperage
[A]
175.0
Maximum motor frequency
[Hz]
70
Minimum motor frequency
[Hz]
30
Maximum suction pressure
[bar]
22.5
Maximum discharge pressure
[bar]
32.5

Dimensions

Suction valve diameter
[inch]
1 5/8
Discharge valve diameter
[inch]
1 1/8
Length
[mm]
638
Height
[mm]
452
Width
[mm]
501

Other

Approved refrigerants
R22, R134a, R404A, R407A, R407C, R407F, R448A, R449A, R450A, R454A, R454C, R455A, R513A
Allowed oil types
POE RL32-3MAF, POE MOBIL EAL Arctic 22 CC
Capacity control
None, Step (option), Inverter (option)
Protection rating
IP54 (IEC34)

Performance

Invalid data supplied. Correct them and try again.
Performance
Evaporation
Condensation

Cooling capacity [kW]

Evaporation temperature [°C]
Condensation temperature [°C]

-45
-40
-35
-30
-25
-20
-15
-10
-5
0
5
7
10
9.89
13.48
17.79
22.97
29.13
36.40
44.90
54.76
15
8.56
12.05
16.19
21.12
26.95
33.83
41.86
51.19
61.93
20
7.21
10.61
14.58
19.26
24.77
31.25
38.83
47.64
57.79
69.39
82.53
25
5.87
9.16
12.97
17.40
22.59
28.68
35.81
44.09
53.67
64.64
77.12
82.54
30
4.54
7.72
11.35
15.54
20.42
26.12
32.80
40.57
49.57
59.92
71.73
76.89
35
6.31
9.75
13.69
18.25
23.58
29.80
37.06
45.49
55.23
66.38
71.27
40
4.93
8.17
11.86
16.11
21.05
26.83
33.58
41.45
50.57
61.07
65.69
45
6.64
10.07
14.00
18.56
23.89
30.13
37.43
45.94
55.79
60.14
50
5.16
8.31
11.92
16.09
20.97
26.71
33.45
41.35
50.56
54.64
55
6.62
9.88
13.66
18.10
23.32
29.50
36.79
45.35
49.17
60
5.00
7.91
11.28
15.26
19.97
25.58
32.26
40.18
62
4.38
7.13
10.34
14.13
18.63
24.01
30.45

Power consumption [kW]

Evaporation temperature [°C]
Condensation temperature [°C]

-45
-40
-35
-30
-25
-20
-15
-10
-5
0
5
7
10
4.88
5.59
6.20
6.71
7.10
7.34
7.43
7.35
15
4.99
5.80
6.53
7.16
7.68
8.06
8.30
8.37
8.25
20
5.03
5.96
6.81
7.57
8.22
8.75
9.13
9.36
9.41
9.27
8.92
25
5.00
6.05
7.02
7.92
8.71
9.38
9.92
10.31
10.53
10.57
10.40
10.28
30
4.90
6.07
7.17
8.21
9.14
9.97
10.67
11.23
11.63
11.85
11.87
11.82
35
6.01
7.26
8.43
9.52
10.51
11.38
12.11
12.68
13.09
13.31
13.35
40
5.88
7.27
8.59
9.84
10.99
12.03
12.94
13.70
14.30
14.72
14.84
45
7.20
8.68
10.09
11.41
12.63
13.72
14.67
15.47
16.10
16.30
50
7.06
8.70
10.27
11.77
13.16
14.45
15.60
16.60
17.44
17.73
55
8.63
10.38
12.06
13.64
15.12
16.47
17.69
18.74
19.12
60
8.49
10.41
12.27
14.05
15.73
17.29
18.72
20.00
62
8.40
10.40
12.34
14.20
15.95
17.60
19.12

Application range

Legend

  • Suction gas temperature: 20°C
  • Suction gas temperature: 0°C
  • Current operating conditions

Dimensions

Dimensions

Dimension A
[mm]
637
Dimension B
[mm]
145
Dimension C
[mm]
88,5
Dimension D
[mm]
355,9
Dimension E
[mm]
24,9
Dimension F
[mm]
265,5
Dimension G
[mm]
354,6

Downloads

AGL_Stream_ST_A2L_A1_4M_6M_EN_Rev04, Technical documentation, [3.2 MB]
Copeland
02-2025
EN
Safety manual, [252.6 KB]
Copeland
03-2024
PL
TI_Semi_Designation_EN_Rev00, Technical documentation, [202.4 KB]
Copeland
09-2024
EN
Declaration, [266.8 KB]
Copeland
08-2024
EN
Declaration, [290.4 KB]
Copeland
04-2025
EN
Catalogue, [31.6 MB]
Copeland
07-2024
EN
AGL_Stream_ST_A2L_A1_4M_6M_EN_Rev04, Technical documentation, EN, Copeland, 02-2025, [3.2 MB]
Safety manual, PL, Copeland, 03-2024, [252.6 KB]
TI_Semi_Designation_EN_Rev00, Technical documentation, EN, Copeland, 09-2024, [202.4 KB]
Declaration, EN, Copeland, 08-2024, [266.8 KB]
Declaration, EN, Copeland, 04-2025, [290.4 KB]
Catalogue, EN, Copeland, 07-2024, [31.6 MB]
