Electronic expansion valve ETS 400L-L

Producer:
Danfoss
Line: ETS
  • Nominal capacity [kW]:
    1,066.00
  • Valve type:
    Stepper
  • Flow direction:
    Bi-flow
  • Body geometry:
    Straightway
  • Inlet connection diameter:
    1 5/8", 2 1/8", 2 5/8"
  • Outlet connection diameter:
    1 5/8", 2 1/8", 2 5/8"
Ask about product

Data

Technical data

Nominal capacity
[kW]
1,066.00
Flow direction
Bi-flow
Maximum working pressure
[bar]
37
Maximal OPD ¹
[bar]
26
Motor coil type
Bipolar
Motor total steps ¹
3,810

Connections data

Connection material
Copper
Inlet connection type
Soldered, ODF (inch)
Inlet connection diameter (A) ¹
1 5/8", 2 1/8", 2 5/8"
Outlet connection type
Soldered, ODF (inch)
Outlet connection diameter (B) ¹
1 5/8", 2 1/8", 2 5/8"
Electrical connection type
M12 connector

Body data

Body geometry
Straightway
Body material
Brass
Manual opening function
Optional
Sight glass ¹
Yes
Gross weight ²
[kg]
3.42
Net weight ²
[kg]
2.86

Other

Product codes ¹
034G3632, 034G3633, 034G3659, 034G3636, 034G3660
Approvals
CE, CMIM, CRN, EAC, LLC CDC TYSK, UA, UKCA, UL
Compatible controllers
EKE 1A, EKE 1B, EKE 1C, MCX, AK-XM 208C
Allowed oil types ¹
Ester, Mineral, None (oil free)
Refrigerant temperature range ¹
-40°C — 70°C, -40°C — 95°C
Refrigerants
R22, R134a, R404A, R407A, R407C, R407F, R410A, R448A, R449A, R450A, R452A, R513A, R515B, R1234ze
Other refrigerants
R407H, R417A, R422A, R422B, R422D, R438A, R442A, R449B, R463A, R507A, R513B, R515A

     1 Depends on product variant.
     2 Presented weight corresponds to heaviest product variant.

Dimensions

Dimension B1
24 mm
Dimension L2
76 mm
Dimension H1
101 mm
Dimension H2
47 mm

Variant 1

Inlet connection type
1 5/8"
Outlet connection type
1 5/8"
Dimension L1
202 mm
Dimension L3
98 mm
Dimension L4
104 mm

Variant 2

Inlet connection type
2 1/8"
Outlet connection type
2 1/8"
Dimension L1
242 mm
Dimension L3
118 mm
Dimension L4
124 mm

Variant 3

Inlet connection type
2 5/8"
Outlet connection type
2 5/8"
Dimension L1
272 mm
Dimension L3
132 mm
Dimension L4
139 mm

Downloads

Data sheet Electric expansion valve ETS
Folder, [5.8 MB]
Danfoss
12-2022
EN
Data sheet Electric expansion valve ETS
Folder, EN, Danfoss, 12-2022, [5.8 MB]
