Electronic expansion valve ETS 8M 40L-16

Producer:
Danfoss
Line: ETS 8M
  • Nominal capacity [kW]:
    40.65
  • Valve type:
    Stepper
  • Flow direction:
    Bi-flow
  • Body geometry:
    Angleway
  • Inlet connection diameter:
    5/8"
  • Outlet connection diameter:
    5/8"
Ask about product

Data

Technical data

Nominal capacity (normal direction)
[kW]
40.650
Nominal capacity (reverse direction)
[kW]
37.930
Flow direction
Bi-flow
Maximum operating pressure
[bar]
49
Maximal OPD
[bar]
39
Maximal reverse OPD
[bar]
32
Motor coil type
Unipolar
Motor total half-steps
500

Connections data

Connection material
Copper
Inlet connection type
Soldered, ODM (inch)
Inlet connection diameter (A)
5/8"
Outlet connection type
Soldered, ODM (inch)
Outlet connection diameter (B)
5/8"

Body data

Body geometry
Angleway
Body material
Stainless steel
Manual opening function
No
Gross weight
[kg]
0.22
Net weight
[kg]
0.15

Other

Product codes
034G8801
Approvals
cURus
Allowed oil types
POE, PVE
Refrigerant temperature range
-30°C — 70°C
Refrigerants
R134a, R290, R32, R404A, R407C, R410A, R448A, R449A, R452A, R452B, R454B, R454C, R513A, R515B, R1234ze
Other refrigerants
R449B

Dimensions

Related products

Downloads

Data sheet Electric expansion valve ETS 8M
Folder, [2.7 MB]
Danfoss
03-2023
EN
Data sheet Electric expansion valve ETS 8M
Folder, EN, Danfoss, 03-2023, [2.7 MB]
