Condensing unit EB-A17-0Y-1M

Condensing unit EB-A17-0Y-1M

Producer:
Frascold
Line: EB
  • Cooling capacity [kW]:
    3.32
  • Displacement [m³/h]:
    6.91
  • Refrigerant:
    R134a, R404A, R448A, R449A, R450A, R452A, R513A
  • Capacity control:
    None, Step (option), Inverter (option)
  • Power supply:
    400V/3Ph/50Hz
Ask about product

Data

Compressor technical data

Compressor model
A1-7Y
Displacement
[m³/h]
6.91
Cylinders quantity
2
Oil charge
[l]
1.00
Oil type
POE32
Type of lubrication
Splash lubrication
Capacity control
None, Step (option), Inverter (option)

Compressor electrical data

Compressor power supply
400V/3Ph/50Hz
Maximum operating current
[A]
3.7
Locked rotor amperage
[A]
13.6
Maximum motor frequency
[Hz]
30
Minimum motor frequency
[Hz]
87
Nominal motor power for 50 Hz
[kW]
0.75
Nominal motor power for 50 Hz
[HP]
1.00
Motor connection
DOL

Condenser data

Fan quantity
1
Fan power supply
230V/1Ph/50Hz
Fans power
[W]
160
Fan current
[A]
1.35
Fan motor type
EC
Inner volume
[dm³]
0.7

Condensing unit data

Receiver volume
[l]
1.5
Net weight (without housing)
[kg]
67.00
Netto weight (with housing)
[kg]
89
Housing
Optional
Approved refrigerants
R134a, R404A, R448A, R449A, R450A, R452A, R513A

Dimensions (without housing)

Length
[mm]
771
Height
[mm]
463
Width
[mm]
660

Connections

Suction valve diameter
[inch]
5/8
Suction valve diameter
[mm]
15.8
Liquid valve diameter
[inch]
3/8
Liquid valve diameter
[mm]
9.5

Standard version equipment

  • compressor
  • air cooled condenser
  • EC fan motors
  • liquid receiver with shut-off valve
  • base mounting
  • high pressure switch with manual reset
  • electric box with fan and pressure switch wiring
  • crankcase heater

Performance

Invalid data supplied. Correct them and try again.
Performance
Evaporation
Ambiance

Cooling capacity [kW]

Evaporation temperature [°C]
Ambient temperature [°C]

-45
-40
-35
-30
-25
-20
-15
-10
-5
53
1.20
48
0.56
0.81
1.11
1.44
1.83
2.27
2.76
43
0.44
0.69
0.98
1.31
1.69
2.11
2.60
3.14
38
0.31
0.56
0.83
1.15
1.51
1.92
2.39
2.93
3.52
33
0.42
0.68
0.97
1.31
1.71
2.16
2.68
3.25
3.90
32
0.44
0.71
1.00
1.35
1.75
2.21
2.73
3.32
3.98
28
0.53
0.80
1.12
1.49
1.92
2.41
2.96
3.58
4.27
27
0.55
0.83
1.15
1.52
1.96
2.46
3.02
3.65
4.35

Power consumption [kW]

Evaporation temperature [°C]
Ambient temperatura [°C]

-45
-40
-35
-30
-25
-20
-15
-10
-5
53
1.53
48
0.91
1.11
1.32
1.53
1.74
1.96
2.19
43
0.76
0.95
1.14
1.32
1.52
1.71
1.91
2.12
38
0.63
0.81
0.98
1.15
1.32
1.50
1.68
1.86
2.06
33
0.69
0.85
1.00
1.16
1.31
1.47
1.64
1.81
1.98
32
0.70
0.85
1.00
1.16
1.31
1.47
1.63
1.80
1.97
28
0.73
0.87
1.01
1.15
1.30
1.44
1.59
1.75
1.91
27
0.74
0.88
1.01
1.15
1.29
1.43
1.58
1.73
1.89

Cooling capacity and power input are presented for maximal fan speed.

Application range

Reference conditions - suction gas temperature: 20°C, subcooling: 0 K.

Dimensions

Symbols

S Safety Valve
AC Condenser
AF Fan motor
DV Discharge valve
LR Liquid receiver
LRV Liquid valve
SV Suction valve



OS* Oil separator Optional equipment
HL* High/Low pressure switch Standard equipment
LL* Liquid line Optional equipment

Dimensions (without housing)

Dimension A
[mm]
771
Dimension B
[mm]
660
Dimension C
[mm]
463

Dimensions (without housing)

Dimension A
[mm]
771
Dimension B
[mm]
684
Dimension C
[mm]
486

Condenser and base

Dimension D
[mm]
721
Dimension E
[mm]
410
Dimension F
[mm]
470
Dimension G
[mm]
115
