Refrigeration compressor SY300-4

Refrigeration compressor SY300-4

Producer:
Danfoss
Line: SY
  • Cooling capacity [kW]:
    41.58
  • Displacement [m³/h]:
    76.1
  • Refrigerant:
    R22, R134a, R407C, R513A
  • Capacity control:
    None
  • Power supply:
    400V/3Ph/50Hz
Ask about product

Data

Technical data

Displacement
[m³/h]
76.1
Swept volume
[cm³]
437.50
Oil type
POE 320SZ
Oil charge
[l]
8.00
Internal free volume (suction)
[dm³]
34.1
Internal free volume (discharge)
[dm³]
5.0
Net weight
[kg]
157.15
Gross weight
[kg]
162.38

Electrical data

Power supply
400V/3Ph/50Hz
Maximum operating current
[A]
69.0
Locked rotor amperage
[A]
270.0
Rated load amps
[A]
49.3
Revolutions per minute
[RPM]
2900
Motor resistance main
[Ω]
0.52

Limits

Maximum suction pressure
[bar]
20.0
Maximum discharge pressure
[bar]
31.8
Maximum suction temperature
[°C]
52.0
Minimum suction temperature
[°C]
-35.0
Maximum discharge temperature
[°C]
150.0
Minimal discharge temperature
[°C]
-35.0

Dimensions

Suction tube diameter ¹
[inch]
1 5/8
Discharge tube diameter ¹
[inch]
1 1/8
Suction valve diameter ²
[inch]
1 5/8
Discharge valve diameter ²
[inch]
1 1/8
Suction connection thread diameter ²
[inch]
2 1/4
Discharge connection thread diameter ²
[inch]
1 3/4
Diameter
[mm]
344
Height
[mm]
738
Oil equalization
1/2" Flare
Oil drain
1/4" Flare



1 For version with brazed connection type.
2 For version with Rotolock connection type.

Other

Product codes
SY300A4CAI, SY300A4CAM, SY300A4CBI, SY300A4CBM, SY300A4PAI, SY300A4PAM, SY300A4PBI, SY300A4PBM
Alternative name
SY300A4CAE, SY300A4CBE, SY300A4PAE, SY300A4PBE
Approved refrigerants
R22, R134a, R407C, R513A
Capacity control
None
Protection rating ³
IP54
Glass mounting
Threaded
Approvals
UL, CE, UKCA

Shipped equipment

Motor protection ⁴
Electronic protection module, 24 V AC, Electronic protection module, 110 / 240 V
Shipped fittings
Suction and discharge solder sleeves, rotolock nuts and gaskets
Shipped mounting ⁵
Mounting kit with grommets and sleeves
Shipped modules
Electronic protection module mounted in terminal box

3 With cable gland.

4 Depends on product version.
5 For version with Rotolock connection type.

Performance

Invalid data supplied. Correct them and try again.
Performance
Evaporation
Condensation

Cooling capacity [kW]

Evaporation temperature [°C]
Condensation temperature [°C]

-20
-15
-10
-5
0
5
10
15
30
31.53
39.32
48.55
59.38
71.98
86.51
103.13
122.01
35
29.98
37.48
46.36
56.78
68.90
82.89
98.90
117.11
40
28.35
35.53
44.03
54.00
65.62
79.04
94.42
111.94
45
26.66
33.50
41.58
51.08
62.16
74.99
89.71
106.51
50
31.39
39.04
48.04
58.56
70.76
84.80
100.84
55
36.43
44.90
54.83
66.37
79.69
94.96
60
41.68
50.98
61.85
74.43
88.89
65
47.06
57.21
69.02
82.64

Power consumption [kW]

Evaporation temperature [°C]
Condensation temperature [°C]

-20
-15
-10
-5
0
5
10
15
30
12.91
13.15
13.46
13.84
14.29
14.83
15.44
16.13
35
14.23
14.46
14.76
15.12
15.57
16.09
16.70
17.39
40
15.71
15.92
16.20
16.55
16.98
17.50
18.10
18.78
45
17.36
17.55
17.81
18.15
18.57
19.07
19.66
20.34
50
19.38
19.63
19.95
20.36
20.85
21.42
22.09
55
21.68
21.98
22.37
22.85
23.41
24.07
60
24.28
24.65
25.11
25.66
26.30
65
27.22
27.66
28.19
28.82

Application range

Legend

  • Suction gas superheating: 5 K
  • Suction gas superheating: 30 K
  • Current operating conditions

Dimensions
