CX screw compressors catalog
Catalogue, [4.4 MB]
Log in to download this file
1 No valve version.
2 Valve version.
Reference conditions - suction gas superheating: 10 K, subcooling: 0 K.
| 1 | High pressure connection | 1/8" NPT |
| 2 | Low pressure connection | 1/8" NPT |
| 3 | High pressure connection | 1/4" SAE x 1/4" SAE |
| 4 | Low pressure connection | 1/4" SAE x 1/4" SAE |
| 5 | Oil charge plug | 3/8" GAS |
| 6 | Crankcase heater | - |
| 7 | Oil level regulator connection | 3/4" NPT |
| 8 | Oil level sight glass | - |
| 9 | Filter clogging sensor connection | 1/2" GAS |
| 10 | Oil cooler connection | 1/2" NPT |
| 11 | Oil drain plug | 1/4" NPT |
| 12 | Oil drain valve | 1/8" NPT |
| 13 | Maximum oil temperature sensor | - |
| 14 | ECO/liquid injection connection | 1 3/8" |
| DV | Discharge valve | |
| SV | Suction valve | |
| SL | Suction line | |
| NP | Nameplate |
