CO₂ (SK, TK) reciprocating compressors catalog
Catalogue, [5.3 MB]
Log in to download this file
* The dimensions are given for SLD version. Valve diameter for OGV version: 5/8" / 16 mm
| 1 | High pressure connection | 1/8" NPT |
| 2 | Low pressure connection | 1/4" NPT |
| 3 | Oil charge plug | 1/4" GAS |
| 4 | Oil level sight glass | 1 1/8" UNEF |
| 5 | Crankcase heater seat | - |
| 6 | Oil drain plug | M12 |
| 12 | Oil return plug | 1/4" NPT |
| 13 | Magnetic plug | 1/2" GAS |
| 14 | Max. discharge temperature sensor connection | 1/8" NPT |
| 16 | Crankcase pressure plug | 1/4" NPT |
| 28 | High pressure side relief valve | - |
| 29 | Low pressure side relief valve | - |
| DV | Discharge valve | |
| SV | Suction valve | |
| NP | Nameplate |
