¹ Ambient temperature: 7°C DB (6°C WB), water temperature: 30°C (inlet) / 35°C (outlet)
² Ambient temperature: 7°C DB (6°C WB), water temperature: 40°C (inlet) / 45°C (outlet)
³ Ambient temperature: 35°C DB, water temperature: 12°C (inlet) / 7°C (outlet)
⁴ Ambient temperature: 35°C DB, water temperature: 23°C (inlet) / 18°C (outlet)
⁵ EN ISO 3744, measured at LNE lab at 1m
| FDCW71VNX-W | FDCW71/100/140VNX-A | ||
| A | Service valve connection (gas side) | ⌀ 15,88 (5/8") Flare | ⌀ 15,88 (5/8") Flare |
| B | Service valve connection (liquid side) | ⌀ 6,35 (1/4") Flare | ⌀ 9,52 (3/8") Flare |
| C | Pipe/cable draw-out hole | ||
| D | Drain discharge hole | ⌀ 20 | ⌀ 20 |
| E | Anchor bolt hole | M10 | M10 |
| F | Cable draw-out hole | ⌀ 30 (front), ⌀ 45 (side), ⌀ 50 (back) |
