1 Possibility to choose power supply type due to supply's peak power
| HMS60-W | HMS100-W | HMS140-S | ||
| XL1 | Heating medium supply | ⌀ 22 mm | ⌀ 22 mm | ⌀ 28 mm |
| XL2 | Heating medium return | ⌀ 22 mm | ⌀ 22 mm | ⌀ 28 mm |
| XL8 | HW heating medium supply | ⌀ 22 mm | ⌀ 22 mm | ⌀ 28 mm |
| XL10 | Drain valve | GW1/2" | GW1/2" | GW1/2" |
| XL11 | Safety assembly | ⌀ 22 mm | ⌀ 22 mm | ⌀ 22 mm, pressure gauge |
| XL52 | Connection, gas line | 1/2" | 5/8" | 5/8" |
| XL53 | Connection, liquid line | 1/4" | j. zewn. VNX-W 1/4" j. zewn. VNX-A 3/8" |
3/8" |
| WM1 | Drain from the drip tray | ⌀ 8 mm × 1.5 mm | ⌀ 8 mm × 1.5 mm | ⌀ 8 mm × 1.5 mm |
| PF1 | Serial number plate |
| PF2 | Plate with the designation of the hydraulic connections |
| PF3 | Warning plate |
