Refrigeration compressor SY240-4

Refrigeration compressor SY240-4

Producer:
Danfoss
Line: SY
  • Cooling capacity [kW]:
    32.80
  • Displacement [m³/h]:
    60.5
  • Refrigerant:
    R22, R134a, R407C, R513A
  • Capacity control:
    None
  • Power supply:
    400V/3Ph/50Hz
Ask about product

Data

Technical data

Displacement
[m³/h]
60.5
Swept volume
[cm³]
347.80
Oil charge
[l]
8.00
Oil type
POE 320SZ
Internal free volume (suction)
[dm³]
34.1
Internal free volume (discharge)
[dm³]
5.0
Net weight
[kg]
151.00
Gross weight
[kg]
166.00

Electrical data

Power supply
400V/3Ph/50Hz
Maximum continuous current
[A]
50.0
Locked rotor amperage
[A]
215.0
Revolutions per minute
[RPM]
2900
Motor resistance main
[Ω]
0.62

Limits

Maximum suction pressure
[bar]
20.0
Maximum discharge pressure
[bar]
31.8
Maximum suction temperature
[°C]
52.0
Minimum suction temperature
[°C]
-35.0
Maximum discharge temperature
[°C]
150.0
Minimal discharge temperature
[°C]
-35.0

Dimensions

Suction tube diameter ¹
[inch]
1 5/8
Discharge tube diameter ¹
[inch]
1 1/8
Suction valve diameter ²
[inch]
1 5/8
Discharge valve diameter ²
[inch]
1 1/8
Suction connection thread diameter ²
[inch]
2 1/4
Discharge connection thread diameter ²
[inch]
1 3/4
Diameter
[mm]
344
Height
[mm]
727
Oil equalization
1/2" Flare
Oil drain
1/4" Flare



     1 For version with brazed connection type.
     2 For version with Rotolock connection type.

Other

Product codes
SY240A4CAI, SY240A4CAM, SY240A4CBI, SY240A4CBM, SY240A4PAI, SY240A4PAM, SY240A4PBI, SY240A4PBM
Approved refrigerants
R22, R134a, R407C, R513A
Capacity control
None
Protection rating ³
IP54
Glass mounting
Threaded

Shipped equipment

Motor protection ⁴
Electronic protection module, 24 V AC, Electronic protection module, 110 / 240 V
Shipped fittings
Suction and discharge solder sleeves, rotolock nuts and gaskets
Shipped mounting ⁵
Mounting kit with grommets and sleeves
Shipped modules
Electronic protection module mounted in terminal box

     3 With cable gland.

     4 Depends on product version.
     5 For version with Rotolock connection type.

Performance

Invalid data supplied. Correct them and try again.
Performance
Evaporation
Condensation

Cooling capacity [kW]

Evaporation temperature [°C]
Condensation temperature [°C]

-20
-15
-10
-5
0
5
10
15
30
24.83
30.97
38.15
46.48
56.08
67.04
79.47
93.50
35
23.59
29.54
36.48
44.52
53.78
64.36
76.37
89.93
40
22.29
28.01
34.69
42.42
51.32
61.50
73.07
86.13
45
26.41
32.80
40.20
48.73
58.48
69.58
82.13
50
30.83
37.88
46.01
55.32
65.93
77.94
55
35.47
43.18
52.02
62.12
73.58
60
40.25
48.61
58.18
69.06
65
45.10
54.11
64.39

Power consumption [kW]

Evaporation temperature [°C]
Condensation temperature [°C]

-20
-15
-10
-5
0
5
10
15
30
10.59
10.71
10.85
11.02
11.24
11.50
11.83
12.23
35
11.67
11.81
11.96
12.15
12.37
12.63
12.95
13.33
40
12.84
12.99
13.16
13.35
13.58
13.84
14.15
14.52
45
14.30
14.48
14.68
14.90
15.16
15.46
15.82
50
15.95
16.16
16.38
16.63
16.93
17.26
55
17.82
18.04
18.29
18.57
18.89
60
19.92
20.16
20.43
20.73
65
22.29
22.54
22.82

Application range

Legend

  • Suction gas superheating: 5 K
  • Suction gas superheating: 30 K
  • Current operating conditions

Dimensions

Downloads

EU Declaration of Conformity
Declaration, [5.3 MB]
Danfoss
07-2021
EN
Catalogue Spare parts and accessories Danfoss Commercial Compressors for hermetic reciprocating and scroll compressors
Catalogue, [2.1 MB]
Danfoss
03-2022
EN
Folder Online Grocery Solutions
Folder, [3.0 MB]
Danfoss
09-2021
EN
Instructions Danfoss scroll compressors DSH / SM / SY / SZ / SH / WSH
User manual, [1.7 MB]
Danfoss
11-2021
EN
Application guidelines Danfoss scroll compressors In parallel installation SM/SY/SZ
Folder, [3.8 MB]
Danfoss
02-2020
EN
Application guidelines Danfoss scroll compressors SM SY SZ
Folder, [4.3 MB]
Danfoss
05-2021
EN
EU Declaration of Conformity
Declaration, EN, Danfoss, 07-2021, [5.3 MB]
Catalogue Spare parts and accessories Danfoss Commercial Compressors for hermetic reciprocating and scroll compressors
Catalogue, EN, Danfoss, 03-2022, [2.1 MB]
Folder Online Grocery Solutions
Folder, EN, Danfoss, 09-2021, [3.0 MB]
Instructions Danfoss scroll compressors DSH / SM / SY / SZ / SH / WSH
User manual, EN, Danfoss, 11-2021, [1.7 MB]
Application guidelines Danfoss scroll compressors In parallel installation SM/SY/SZ
Folder, EN, Danfoss, 02-2020, [3.8 MB]
Application guidelines Danfoss scroll compressors SM SY SZ
Folder, EN, Danfoss, 05-2021, [4.3 MB]
