Refrigeration compressor SH240-4

Refrigeration compressor SH240-4

Producer:
Danfoss
Line: SH
  • Cooling capacity [kW]:
    32.79
  • Displacement [m³/h]:
    39.6
  • Refrigerant:
    R410A
  • Capacity control:
    None
  • Power supply:
    400V/3Ph/50Hz
Ask about product

Data

Technical data

Displacement
[m³/h]
39.6
Swept volume
[cm³]
227.60
Oil charge
[l]
6.70
Oil type
POE 160SZ
Internal free volume (suction)
[dm³]
28.5
Internal free volume (discharge)
[dm³]
2.5
Net weight
[kg]
107.00
Gross weight
[kg]
112.35

Electrical data

Power supply
400V/3Ph/50Hz
Locked rotor amperage
[A]
215.0
Revolutions per minute
[RPM]
2900
Motor resistance main
[Ω]
0.62

Limits

Maximum suction pressure
[bar]
48.7
Maximum discharge pressure
[bar]
31.1
Maximum suction temperature
[°C]
52.0
Minimum suction temperature
[°C]
-35.0
Maximum discharge temperature
[°C]
150.0
Minimal discharge temperature
[°C]
-35.0

Dimensions

Suction tube diameter
[inch]
1 5/8
Discharge tube diameter
[inch]
1 1/8
Diameter
[mm]
318
Height
[mm]
683
Oil equalization
2 1/4" Rolotock
Oil drain
1/4" Flare

Other

Product codes
120H0291, 120H0292, 120H0299, 120H0300
Approved refrigerants
R410A
Capacity control
None
Protection rating ¹
IP54
Glass mounting
Threaded

Shipped equipment

Motor protection ²
Electronic protection module, 24 V AC, Electronic protection module, 110 / 240 V
Shipped mounting
Mounting kit with rigid grommets, bolts, nuts, sleeves and washers
Shipped modules
Electronic protection module mounted in terminal box

     1 With cable gland.

     2 Depends on product version.

Performance

Invalid data supplied. Correct them and try again.
Performance
Evaporation
Condensation

Cooling capacity [kW]

Evaporation temperature [°C]
Condensation temperature [°C]

-30
-25
-20
-15
-10
-5
0
5
10
15
20
18.75
23.55
29.22
35.87
43.63
52.61
62.92
74.69
25
17.43
22.17
27.72
34.20
41.71
50.38
60.33
71.66
84.51
30
16.12
20.78
26.18
32.45
39.69
48.02
57.56
68.44
80.75
94.64
35
19.35
24.58
30.60
37.54
45.50
54.61
64.99
76.75
90.01
40
17.87
22.89
28.64
35.24
42.81
51.46
61.32
72.49
85.10
45
21.10
26.55
32.79
39.93
48.09
57.39
67.94
79.87
50
24.31
30.15
36.83
44.47
53.19
63.09
74.31
55
27.32
33.51
40.60
48.70
57.93
68.40
60
29.94
36.45
43.91
52.42
62.13
65
38.79
46.57
55.47

Power consumption [kW]

Evaporation temperature [°C]
Condensation temperature [°C]

-30
-25
-20
-15
-10
-5
0
5
10
15
20
8.52
8.59
8.64
8.68
8.74
8.82
8.96
9.16
25
9.49
9.58
9.64
9.68
9.73
9.80
9.91
10.07
10.30
30
10.55
10.66
10.74
10.79
10.83
10.89
10.97
11.10
11.29
11.56
35
11.86
11.95
12.02
12.06
12.11
12.17
12.27
12.43
12.65
40
13.18
13.30
13.38
13.44
13.48
13.53
13.61
13.73
13.90
45
14.80
14.90
14.97
15.02
15.06
15.12
15.21
15.34
50
16.59
16.68
16.73
16.77
16.82
16.88
16.99
55
18.57
18.64
18.69
18.72
18.77
18.85
60
20.77
20.82
20.85
20.89
20.95
65
23.22
23.25
23.29

Application range

Legend

  • Suction gas superheating: 5 K
  • Suction gas superheating: 30 K
  • Current operating conditions

Dimensions

Downloads

EU Declaration of Conformity
Declaration, [5.3 MB]
Danfoss
07-2021
EN
Catalogue Spare parts and accessories Danfoss Commercial Compressors for hermetic reciprocating and scroll compressors
Catalogue, [2.1 MB]
Danfoss
03-2022
EN
Folder Online Grocery Solutions
Folder, [3.0 MB]
Danfoss
09-2021
EN
Application guidelines Danfoss scroll compressors SH - In parallel installation
Folder, [12.3 MB]
Danfoss
03-2020
EN
Application guidelines Danfoss scroll compressors SH090 to SH485 - single
Folder, [3.2 MB]
Danfoss
05-2021
EN
Application guidelines Hybrid tandem VSH with SH - R410A
Folder, [2.5 MB]
Danfoss
04-2012
EN
Lubricant safety data sheet
User manual, [739.8 KB]
Danfoss
01-2020
PL
EU Declaration of Conformity
Declaration, EN, Danfoss, 07-2021, [5.3 MB]
Catalogue Spare parts and accessories Danfoss Commercial Compressors for hermetic reciprocating and scroll compressors
Catalogue, EN, Danfoss, 03-2022, [2.1 MB]
Folder Online Grocery Solutions
Folder, EN, Danfoss, 09-2021, [3.0 MB]
Application guidelines Danfoss scroll compressors SH - In parallel installation
Folder, EN, Danfoss, 03-2020, [12.3 MB]
Application guidelines Danfoss scroll compressors SH090 to SH485 - single
Folder, EN, Danfoss, 05-2021, [3.2 MB]
Application guidelines Hybrid tandem VSH with SH - R410A
Folder, EN, Danfoss, 04-2012, [2.5 MB]
Lubricant safety data sheet
User manual, PL, Danfoss, 01-2020, [739.8 KB]
